Description

Performance parameters

1. Maximum payload: 3 kg;
2. Endurance time (with tilt load): 55±5 minutes;
3. Flight altitude: ≥5000 meters;
4. Maximum control radius: 10 kilometers (line-of-sight, clear environment);
5. Maximum ascent/descent speed: Ascent 4 m/s, Descent 3 m/s;
6. Maximum cruising speed: 15 m/s;
7. Hovering accuracy (with RTK fixed): Horizontal ±0.1 m, Vertical ±0.1 m;
8. Convenience: Ready to fly out of the box, preparation time less than 1 minute.

Function

1. Autonomous flight: Conducts autonomous flights based on ground station software planning (remote control available for emergency operations);
2. Integrated communication control link for image and data transmission, returning FPV flight imagery;
3. Low voltage protection with autonomous alerts, return-to-home, and landing;
4. Intelligent battery with smart charge and discharge management to extend cell life;
5. Compatible with high-capacity batteries, 20A half-hour super fast charging;
6. Optional 4G communication module;
7. Optional visual-assisted landing function;
8. Supports cloud services;
9. Universal electromechanical payload interface;
10. Ground station software for real-time monitoring of device status;
11. Terrain-following flight function;
12. Precision power line inspection routes;
13. Pre-flight obstacle avoidance function;
14. Supports RTK positioning;
15. Supports dual-antenna orientation;
16. Supports PPK for precise photo location recording;
17. Supports hydrological route planning, flight, flow rate calculation, and report export;
18. Supports laser radar calibration route planning and flight;
19. Ground station software supports online firmware upgrades.

Other parameters

1. MTBF (Mean Time Between Failures): 150 flight hours or 150 flights;
2. MTTR (Mean Time To Repair): 2 hours;
3. Operating temperature: -10°C to 40°C;
4. Storage temperature: 0°C to 40°C;
5. Operating environment relative humidity: 90%;
6. Wind resistance level: Level 5 (ground wind speed ≤ 9 m/s);
7. Rain resistance level: IPX4 (moderate rain).
