Description

Specifications

1. Maximum payload: 7 kg
2. Endurance time:
– With 2 kg payload: 55 minutes
– With 3 kg payload: 50 minutes
3. Flight altitude: ≥5000 meters
4. Maximum control radius: 10 kilometers (line-of-sight, clear environment)
5. Maximum ascent/descent speed: Ascent 4 m/s, Descent 3 m/s
6. Maximum cruising speed: 15 m/s
7. RTK accuracy: Horizontal: 10 mm + 1 ppm; Vertical: 20 mm + 1 ppm
8. Convenience: Ready to fly out of the box, preparation time less than 1 minute

Functions

1. Autonomous flight: Conducts autonomous flights based on ground station software planning (remote control available for emergency operations);
2. Integrated communication control link: Transmits FPV flight imagery;
3. Low voltage protection: Autonomous alerts, return-to-home, and landing;
4. Intelligent battery: Smart charge and discharge management to extend cell life;
5. Compatible with high-capacity batteries: 20A half-hour super fast charging;
6. Optional 4G communication module;
7. Optional visual-assisted landing function;
8. Supports cloud services;
9. Universal electromechanical payload interface;
10. Ground station software: Real-time monitoring of device status;
11. Terrain-following flight function;
12. Precision power line inspection routes;
13. Pre-flight obstacle avoidance function;
14. Supports RTK positioning;
15. Supports RTK dual-antenna orientation;
16. Supports PPK for precise photo location recording;
17. Supports hydrological route planning, flight, flow rate calculation, and report export;
18. Supports laser radar calibration route planning and flight;
19. Ground station software supports online firmware upgrades.
